Single Flute End Mill Cutting Bit

In stock - 23 items available
SKU: SFE001
Regular price R 129.95 incl. VAT
Please choose cutter diameter

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Single Flute tungsten carbide end mill to cut a wide variety of materials. The single flute allows more material to be removed per revolution of the bit which is good for materials like aluminium and plastics. It also allows spindles which do not have a low speed setting, to cut material more effectively.

Specifications:

  • Bit Type: Single flute end mill cutter
  • Material: Tungsten Carbide
  • Diameter: 1mm, 1.5mm, 2mm, 2.5mm, 3.175mm, 4mm, 6mm (Please select from the menu above)
  • Shank Diameter: 3.175mm (1/8')
  • Materials to cut: Wood, Plastic, Aluminium, Brass, Composites, Cardboard and Structural foam
  • Cutting Edge Length for 1mm bit: 4mm
  • Cutting Edge Length for 1.5mm bit: 6mm
  • Cutting Edge Length for 2mm bit: 8mm
  • Cutting Edge Length for 2.5mm bit: 12mm
  • Cutting Edge Length for 3.175mm bit: 25mm
  • Cutting Edge Length for 4mm bit: 15mm (Shank Diameter: 4mm)
  • Cutting Edge Length for 6mm bit: 15mm (Shank Diameter: 6mm)
  • Cutting Edge Length for 8mm bit: 20mm (Shank Diameter: 8mm)
